AVR300 SURROUND SOUND RECEIVER
- 72 -
C220,C221,C223,C225,C227,C229,C230, C238,
C239,C254
157D-106M-K-IUI CE 16V 10UF 20% RLT 5X11
C201,C203,C219 157D-476M-K-IUI CE 16V 47UF 20% RLT
C215,C216,C217,C218 157F-105M-K-IUI CE 50V 1UF 20% RLT 5X11
DIODES
D215 4804-0040-2 DIODE IN4004 AT
D201,D202,D203,D204,D205,D206,D207,
D208,D209,D210,D211,D212,D213
4804-1480-3 DIODE LL4148 SM
Z250,Z252,Z254,Z256 4837-13C1-2 DZ 1/2W 13VC MTZJ13C
Z232,Z233 4837-3V36-2 DZ 1/2W +-5% 3.3V TEMIC
Z251,Z253,Z255 4837-6B81-2 DZ 1/2W 6.49~6.83V ROHM
WAFERS/SOCKETS
P805A 2102-100S-003 WAFER 10 PIN P2
JACKS/SOCKETS
JA251,JA253,JA255 2113-3056-0 JACKS D3.5 VERTICAL DUAL
DB201 2113-3060-0 DB9 MALE D SUB
COILS
L201,L202 1801-100K-M COIL 10UH 10% BL7.0
TRANSISTOR
Q236 485A-1140-3 TR DTA114YKA SMD
Q230,Q231 485A-949O-5 TR 2SA949-O HFE 70-140
Q208,Q209,Q211,Q212,Q215,Q217,Q219, Q220,
Q221,Q222,Q223,Q226,Q228,Q229, Q233,
Q234, Q235,Q257
485C-1140-3 TR DTC114YKA 2216470R2
Q210,Q213,Q214,Q218 485C-2229-5 TR 2SC2229-0 HFE 70-140
RESISTOR
R236,R260,R269 4715-101A-2 RMF 1/4W 100R 1% AT
R298 4717-100A-2 RMF 1/2W 10R 1% AT
R268 4718-101J-C-X RMF 1W 100R 5% ATS METAL
R243,R267 4720-102J-J RMG 1/10W 1K 5% 0805
R254,R262,R265,R278,R299 4720-103J-J RMG 1/10W 10K 5% 0805
R274,R287 4720-122J-J RMG 1/10W 1.2K 5% 0805
R256,R280,R301,R303 4720-152J-J RMG 1/10W 1.5K 5% 0805
R289 4720-153J-J RMG 1/10W 15K 5% 0805
R252,R275 4720-182J-J RMG 1/10W 1.8K 5% 0805
R292 4720-202J-J RMG 1/10W 2K 5% 0805
R306,R307 4720-221J-J RMG 1/10W 220R 5% 0805
R247,R271,R296,R304,R305 4720-222J-J RMG 1/10W 2.2K 5% 0805
R258,R282 4720-223J-J RMG 1/10W 22K 5% 0805
Reference No. Part No. Description
To Next Page
