- 73 -
AVR300 SURROUND SOUND RECEIVER
R249,R273 4720-274J-J RMG 1/10W 270K 5% 0805
R237,R250,R261,R270,R308,R309,R310, R311 4720-302J-J RMG 1/10W 3K 5% 0805
R251,R257,R276,R281,R300,R302 4720-332J-J RMG 1/10W 3.3K 5% 0805
R242,R266,R291,R293,R294 4720-471J-J RMG 1/10W 470R 5% 0805
R259,R283 4720-472J-J RMG 1/10W 4.7K 5% 0805
R255,R279 4720-474J-J RMG 1/10W 470K 5% 0805
R253,R277 4720-684J-J RMG 1/10W 680K 5% 0805
R244,R245 4720-750J-J RMG 1/10W 75R 5% 0805
IC
U206 3130-2520-2 IC 7812H 12V REG, T0220F
U205,U209 3130-9130-0 IC 74HCT4094D SMD S016
U204 3131-9470-0 IC MAX232D SO16
U207,U208 3132-0620-0 IC TS972ID OPA AMP SMD
SWITCH
SW201 5200-3530-0 SWITCH,110-220V DPDT
R238,R239,R241,R246,R263,R284,R286, R295 5201-0000-0 RAYCHEM POLYSWITCH RXE01
WIRE
G2 7012-6740-0 CONN WIRE UL1015 18AWG
P205A 7012-6750-0 CONN WIRE 6P P=2.5 26AWG
P122B 7012-6758-0 CONN WIRE 4P P=2.5 AWG26
G1 7012-6785-0 CONN WIRE UL1015 18AWG
PC BOARD
2000 1725-693A-0001 PCB DSP/RS232/AUDIO
MISCELLANEOUS
OP201,OP202 4816-N135-3 OPTOCOUPLER 6N135 DIP8
MAIN SW ASSY
PC BOARD
PCB-AL050C-SW PCB ASSY MAIN SW AL050C
CAPACITORS
C870 150T-152M-5-XO CC 400V 1500P 20% RL
SWITCH
SW803 5200-4868-0 POWER SWITCH TV-8 10A
WIRE
P870B-A 7012-6690-0 CONN WIRE UL1672 18AWG
Reference No. Part No. Description
