Arcam AVR300 Service Manual

AVR300 SURROUND SOUND RECEIVER
- 74 -
PC BOARD
8020 1725-695A-0001 PCB AMP1/AMP2/SW/RECT/
TUNER ASSY
PC BOARD
* CE BLACK / CE SILVER PCB-AL050C-TUNE PCB ASSY TUNER AL050C
* UL BLACK / UL SILVER PCB-AL052C-TUNE PCB ASSY TUNER AL052C
CAPACITORS
C914,C915,C945,C982 150F-101J-5-IF CC 50V 100pF 5% RL 5x3.5
C381,C382,C383,C384,C385,C386 150F-101K-2-FC CC 50V 100pF 10% AT 3.5x
C912,C913 150F-102K-5-IF CC 50V 1000pF 10% RL 5x3
C922 150F-103K-5-II CC 50V 0.01uF 10% RL 5x5
C911 150F-200J-5-GG CC 50V 20pF 5% RL 4x4
C901,C902,C903,C930,C932,C941,C949, C950,
C968,C974,C976,C978,C987,C998
150F-223K-2-FD CC 50V 0.022uF 10% AT
C981 150F-223Z-5-UG CC 50V 0.022uF +80/-20%
C916 150F-331K-5-GE CC 50V 330pF 10% RL 4x3
C985 150F-561K-5-GG CC 50V 560pF 10% RL 4x4
C991 153F-102J-5-IM CM 50V 1000PF 5% RL 5x7
C961,C962 153F-152J-5-JM CM 50V 1500PF 5% RL
C970 153F-223J-5-LQ CM 50V 0.022UF 5% RL
C953,C954,C965 153F-272J-5-JM CM 50V 2700PF 5% RL
C926 153F-333J-5-NLM CM 50V 0.033uF 5% RL 7.5
C973 153F-473J-5-NLM CM 50V 0.047uF 5% RL 7.5
C995,C996 153H-471J-9-NLV CM 100V 470P 5% RB
C904,C928,C975 157D-106M-K-IUI CE 16V 10UF 20% RLT 5X11
C906,C931,C986,C990 157D-107M-K-IUI CE 16V 100UF 20% RLT
C959,C960,C963,C964,C979 157D-226M-K-IUI CE 16V 22UF 20% RLT 5X11
C969 157D-476M-K-IUI CE 16V 47UF 20% RLT
C942,C980 157D-477M-K-OVI CE 16V 470UF 20% RLT
C946,C948,C977 157F-105M-K-IUI CE 50V 1UF 20% RLT 5X11
C929 157F-224M-K-IUI CE 50V 0.22UF 20% RLT
C927,C943,C951 157F-225M-K-IUI CE 50V 2.2U 20% RLT
C947,C967 157F-474M-K-IUI CE 50V 0.47UF 20% RLT
C944 157F-475M-K-IUI CE 50V 4.7UF 20% RLT
C971 15CH-080D-5-GG CTC 0/60 8pF 0.5pF RL
C924,C925 15CH-200J-5-GG CTC 0/60 20pF 5% RL 4x4
C988,C989 15CH-300J-5-IG CTC 0/60 30pF 5% RL 5x4
DIODES
D901 4837-4C20-2 DZ 1/2W 5.0-5.2V AT
D902 4837-7C20-2 DZ 1/2W 9.1-9.5V AT
Reference No. Part No. Description
