Arcam AVR300 Service Manual

- 75 -
AVR300 SURROUND SOUND RECEIVER
WAFERS/SOCKETS
J703B 2101-1521-0 SOCKET (PCB/PCB) 12P
J704B 2101-1601-0 SOCKET (PCB/PCB) 16P
M901 *UL BLACK / UL SILVER 2107-0642-1 ANT-TERMINAL F - TYPE
M901 *CE BLACK / CE SILVER 2107-0682-0 ANT-TERMINAL (DIN-TYPE)
JACKS/SOCKETS
P901 2113-1160-0 WAFER 2P ST. P=2.5 NH
1002 2113-1774-0 JACK RCA 6P R/W GOLD W/O
COILS
L902,L905,L906,L985 1801-101K-M COIL 100UH 10%
L901 1801-220K-M COIL 22UH 10% AL BL7
CRYSTAL
M905 2300-0440-0 CRYSTAL 7.2MHZ 20PPM
M985 2300-1220-0 CRYSTAL 4.332MHZ
CERAMIC FILTERS
M902,M903,M904 2701-0010-1 CF10.7 +-30
M911 2701-0680-0 CF 450 +-1
TRANSISTOR
Q902 4851-9230-5 TR 2SC1923-0 HFE 70-140
Q903,Q945 485A-114E-5 TR DTA114ESA ROHM
Q904,Q905 485C-114E-5 TR DTC114ES
Q901 485C-945P-5 TR 2SC945P HFE 200-400
Q922,Q923,Q942 4860-1590-5 TR 2SC1740S
Q925,Q926,Q943,Q944 4860-8120-G TR 2SD1468S TPS ROHM
RESISTOR
R911 4711-101A-2 RMF 1/8W 100R 1% AT
R912,R914,R916,R919,R920,R921,R922,R923,
R924,R951,R968,R985,R986,R987
4711-102A-2 RMF 1/8W 1K 1% AT
R906,R915,R927,R933,R947,R948,R954,R972,
R988
4711-103A-2 RMF 1/8W 10K 1% AT
R340,R342,R382,R384,R386,R388,R944,R963,
R964,R974
4711-104A-2 RMF 100K 1/8W 1% AT
R903 4711-123A-2 RMF 1/8W 12K 1% AT
R973 4711-183A-2 RMF 1/8W 18K 1% AT
R902,R926,R931,R955 4711-220A-2 RMF 1/8W 22R 1% AT
R928 4711-221A-2 RMF 1/8W 220R 1% AT
R952,R953 4711-223A-2 RMF 1/8W 22K 1% AT
R957,R958 4711-272A-2 RMF 1/8W 2.7K 1% AT
R341,R381,R383,R385,R387,R389,R904,R909,
R910
4711-331A-2 RMF 1/8W 330R 1% AT
Reference No. Part No. Description
