AVR300 SURROUND SOUND RECEIVER
- 76 -
R907,R929,R946,R949 4711-332A-2 RMF 1/8W 3.3K 1% AT
R901 4711-333A-2 RMF 1/8W 33K 1% AT
R959,R960 4711-334A-2 RMF 1/8W 330K 1% AT
R945 4711-392A-2 RMF 1/8W 3.9K 1% AT
R908,R961,R962 4711-471A-2 RMF 1/8W 470R 1% AT
R942 4711-472A-2 RMF 1/8W 4.7K 1% AT
R913 4711-510A-2 RMF 1/8W 51R 1% AT
R975 4711-563A-2 RMF 1/8W 56K 1% AT
R905 4711-681A-2 RMF 1/8W 680R 1% AT
R950 4711-684A-2 RMF 1/8W 680K 1% AT
R989 4711-752A-2 RMF 1/8W 7.5K 1% AT
R925 4711-820A-2 RMF 1/8W 82R 1% AT
R943 4711-822A-2 RMF 1/8W 8.2K 1% AT
IC
U901 3130-8180-0 IC LA1837 AM/FM IF
U903 3131-3760-0 IC LC7218 PLL FREQ
U902 3131-9040-0 IC LC72723M RDS
SEMI FIXED
R956 4756-1036-3-06 SVR 10K H3 7X7.6 RH0615C
R941 4756-2236-3-06 SVR 22K H3 7X7.6 RH0615C
SWITCH
SW901 5200-3281-0-06 SW COMAX
TUNER
1300-0800-0 TUNER ENV17103G1 CE VER
PC BOARD
9000 1725-694A-0001 PCB KEY/TUN/PSU/PHONE
MISCELLANEOUS
GND 4132-1061-0 SOLDER TAG
L971 5600-3280-G COIL MW RF BLOCK
L903,L904 5600-3386-S COIL MPX LPF NMC-4085
L941 5600-3396-S COIL FM DET-1 10.7MHZ
L942 5600-3406-S COIL FM DET-2 10.7MHZ
L972 5600-3416-S COIL AM IFT NMIF-4062
VIDEO ASSY
PC BOARD
PCB-AL050C-VIDEO PCB ASSY VIDEO AL050C
Reference No. Part No. Description
