AVR300 SURROUND SOUND RECEIVER
- 78 -
WAFERS/SOCKETS
P803 2101-1601-0 SOCKET (PCB/PCB) 16P
P802 2101-1801-0 SOCKET (PCB/PCB) 10P
P801 2102-021S-004 2P ST.WAFER
P803B 2102-061S-004 6P ST. WAFER
P801A 2102-100S-003 WAFER 10 PIN P2
JACKS/SOCKETS
AV,DVD IN,MONI,SAT IN,VCR1 IN,VCR1 OUT,
VCR2 IN,VCR2 OUT
2113-3052-0 1P RCA YELLOW 1P
COILS
L802,L804,L805,L806,L811,L812,L813,L814,
L815, L816
1801-101K-M COIL 100UH 10%
L818 1801-270K-M COIL 27 UH,10%,AL,BL7
L801 1801-2R2M-M COIL 2.2UH 20% AL BL7
L819 1801-3R9K-M COIL 3.9U 10% BL=7MM
L809 1807-270J-O COIL 27UH 5% 7.2X8 RLT
CRYSTAL
X804 2300-2350-0 CRTSTAL HC-49/V03 3.5795
X803 2300-2360-0 CRTSTAL HC-49/V03 4.4336
X801 2300-3020-0 X’TAL 14.318MHZ +-20PPM
X802 2300-3030-0 X’TAL 17.734MHZ +-20PPM
TRANSISTOR
Q809,Q810,Q812,Q813,Q825,Q827,Q832, Q834,
Q842
485A-933S-5 TR 2SA933S HFE 120-560
Q822,Q823,Q824,Q835,Q836,Q837,Q838, Q839,
Q9011,Q9013,Q9014
485C-114E-5 TR DTC114ES
Q801,Q826,Q828,Q829,Q830,Q831,Q833, Q840,
Q841
4860-1590-5 TR 2SC1740S
Q802,Q803,Q804,Q805,Q806,Q821,Q843,
Q9012, Q910,
4860-8120-G TR 2SD1468S TPS ROHM
RESISTOR
R994 4711-100A-2 RMF 1/8W 10R 1% AT
R849,R863,R929,R938,R951,R955 4720-000J-J RMG 1/10W 0R 5% 0805
R892,R893,R9010,R939,R941,R945,R946,
R947, R959,R989
4720-101J-J RMG 1/10W 100R 5% 0805
R801,R802,R803,R804,R805,R806,R807, R808,
R809,R819,R845,R862,R9018,R914, R916,R917
,R952,R956,R971,R972,R973, R975,R976,R977,
R978,R985,R988
4720-102J-J RMG 1/10W 1K 5% 0805
R850,R858,R907,R909,R910,R911,R912, R948,
R949,R953,R957,R979
4720-103J-J RMG 1/10W 10K 5% 0805
R810,R984 4720-104J-J RMG 1/10W 100K 5% 0805
R974 4720-113A-J RMG 1/10W 11K 1% 0805
Reference No. Part No. Description
To Next Page
