Arcam AVR300 Service Manual

- 79 -
AVR300 SURROUND SOUND RECEIVER
R818 4720-121J-J RMG 1/10W 120R 5% 0805
R828,R832,R889,R891,R895 4720-122J-J RMG 1/10W 1.2K 5% 0805
R836,R896,R9012 4720-123J-J RMG 1/10W 12K 5% 0805
R816,R991 4720-152J-J RMG 1/10W 1.5K 5% 0805
R9014 4720-153J-J RMG 1/10W 15K 5% 0805
R966 4720-182J-J RMG 1/10W 1.8K 5% 0805
R861,R993 4720-202J-J RMG 1/10W 2K 5% 0805
R814,R897,R898,R986 4720-221J-J RMG 1/10W 220R 5% 0805
R839,R937 4720-222J-J RMG 1/10W 2.2K 5% 0805
R987 4720-271J-J RMG 1/10W 270R 5% 0805
R821 4720-272J-J RMG 1/10W 2.7K 5% 0805
R982 4720-273J-J RMG 1/10W 27K 5% 0805
R981 4720-274J-J RMG 1/10W 270K 5% 0805
R950,R954 4720-301J-J RMG 1/10W 300R 5% 0805
R846,R852,R884,R886,R887,R888,R913, R967 4720-302J-J RMG 1/10W 3K 5% 0805
R965,R983 4720-303J-J RMG 1/10W 30K 5% 0805
R851,R940 4720-330J-J RMG 1/10W 33R 5% 0805
R831,R968 4720-331J-J RMG 1/10W 330R 5% 0805
R919 4720-332J-J RMG 1/10W 3.3K 5% 0805
R838,R848 4720-333J-J RMG 1/10W 33K 5% 0805
R9011 4720-362J-J RMG 1/10W 3.6K 5% 0805
R830,R9016 4720-392J-J RMG 1/10W 3.9K 5% 0805
R915,R958 4720-471J-J RMG 1/10W 470R 5% 0805
R813,R841,R860,R9013 4720-472J-J RMG 1/10W 4.7K 5% 0805
R820,R980 4720-473J-J RMG 1/10W 47K 5% 0805
R990 4720-511J-J RMG 1/10W 510R 5% 0805
R969 4720-512J-J RMG 1/10W 5.1K 5% 0805
R856,R894,R899,R900,R901,R902 4720-561J-J RMG 1/10W 560R 5% 0805
R817,R829,R833 4720-682J-J RMG 1/10W 6.8K 5% 0805
R918 4720-684J-J RMG 1/10W 680K 5% 0805
R822,R823,R824,R825,R826,R827,R840, R842,
R843,R879,R881,R883,R921,R922, R923,R924,
R925,R926,R928,R930,R931, R932,R933,R934,
R935,R942,R943,R944, R960,R961,R962,R963
4720-750J-J RMG 1/10W 75R 5% 0805
R811,R9015 4720-752J-J RMG 1/10W 7.5K 5% 0805
R864,R865,R866,R867,R868,R869,R870, R871,
R872,R873,R874,R875,R876,R877, R878
4720-820J-J RMG 1/10W 82R 5% 0805
R834,R835,R890,R903,R904,R905,R992 4720-821J-J RMG 1/10W 820R 5% 0805
R970 4720-822J-J RMG 1/10W 8.2K 5% 0805
R815 4720-824J-J RMG 1/10W 820K 5% 0805
IC
U801,U803,U804,U808,U809,U812,U818 3131-3730-0 IC BA7625 2X5CH
U810 3131-3750-0 IC LC74763-9012 OSD
U806,U807,U811,U814,U815,U816,U817, U821 3131-7690-0 IC BA7623 VIDEO SOP8 ROH
U813 3132-0990-0 IC TA1270BF VIDEO CHROMA
Reference No. Part No. Description
