42 Dishwasher / User’s Manual/48 EN
Maintenance and cleaning

Clean the impellers at least once a
week in order for the machine operates
efficiently.

Check if the holes on the lower impeller
(1) are clogged. If they are clogged,
remove and clean the impeller. Pull the
lower impeller up to remove it (A, B).

Check if the holes on the upper
impeller (1) are clogged. If they
are clogged, remove and clean the
impeller. Turn its nut to left to remove
the upper impeller (A, B).
Make sure that the nut is tightened well
when installing the upper impeller.
