Ardo Master - INITIAL OPERATION: FOOT SWITCH; Foot Switch Operation and Connection

Ardo medical AG 10 Operating Instructions
Master and Senator
Subject to modifications
Foot switch
Foot switch is optionally available
The pneumatic foot switch allows switching the pump unit ON and OFF with the foot.
Push the pneumatic tube of the foot switch onto
the connection nipple all the way to the limit.
Support for foot switch with integrated air tube winder,
suitable for fitting rail.
(Optionally available bracket for storing the footswitch
when moving the pump or when not in use.)
2
1
1
2
