Argox CP-2240 - Page 27

2 Get started Loading Ribbon
22
5. Install the other ribbon roll and rotate it until the notches align and lock
into the left side of Ribbon Pick-up hub, and then the right.
Note:
The Ribbon Supply Holder accepts the coated side of ribbon to
be wound ink-side IN or wound ink-side OUT.
Note:
The Ribbon Pick-up Holder accepts the coated side of ribbon to
be wound ink-side OUT only.
