Argox D4 250 - System Mode

1 Introduction Printer lights
9
1.4.2 System mode
The system mode consists of status light color combinations. It contains a
list of commands for you to select and run.
To enter the system mode and run the command, do the following:
1. Turn off the printer.
2. Press and hold the FEED button, and turn on the printer.
3. Both status lights glow solid amber for a few seconds. Next, they turn to
green shortly, and then turn to other colors.
4. When status lights show the color combination you need, release the
FEED button immediately.
5. Press the FEED button to run the command.
The following table is the command list of the system mode.
LED 2
LED 1
Command
Red
Green
Transmissive Sensor Calibration (Section 3.1)
Amber
Green
Reflective Sensor Calibration (Section 3.1)
Red
Red
Resetting Your Printer (Section 3.3)
Amber
Red
Reserved
Green
Red
Disable Checking RTC Battery Charge
Red
Amber
Reserved
Green
Amber
Self Test (Section 3.2)
