Setting the limit switches:
The travel limit switch (changeover) is not
activated in the end position (round notch
in the switching cam).
Standard works settings:
LS1 and LS3: for 90° position
LS2 and LS4: for 0° position
There may be different, order-specific
settings.
Check the setting necessary for the ap-
plication before commissioning.
The end-position setting can be adjusted
by moving the individual switching cams
(they are secured with socket set screws)
(see the Chapter “Maintenance and re-
placement parts”)
.
Make sure the unit is securely mount-
ed and that all connections have been
correctly executed.
After connecting the cable at the termi-
nals:
Fit the cover plate (cable cover) in its
original position so that neither the ca-
ble nor individual leads are damaged
or crushed. Tighten the screws (4.22)
with suitable torque.
Fit the cover (2.6) in its original posi-
tion (the arrow on the cover must point
towards the cable glands): the 180°-
marking must point towards the cable-
gland side.
CAUTION
Danger
of crushing and damaging
the
sealing element (O-ring) be-
tween
the body and the cover.

During assembly, take care
that neither the sealing ele-
ments nor the ATEX sealing
surfaces on the body, cover or
shaft are damaged.
Tighten the screws (2.19) with suitable
torque.
