36
8.0 Technical Description
8.1 Basic Technical Specifications
Maximum deviation from fixed factors: ±5% (unless otherwise noted)
Total weight: 2.5kg
Environmental
Operation
Temperature –5°C to +40°C
Relative humidity 10% to 80%, non-condensing
Storage and transportation
Temperature –20°C to +60°C
Relative humidity 95%, non-condensing
Do not use the NOMAD Pro 2 outside of the temperature and relative humidity ranges
specified.
Classification / Specification Compliance
IEC 60601-1 (Amnd 1 & 2), 60601-1-3,
60601-2-7; 21 CFR 1020.30 & 1020.31 Internally Powered, Type BF
MDD (93/42/EEC): Annex IX Class IIb
IPX specification IPX0; do not operate under wet conditions
Mode of operation Intermittent operation
Conductive connection to patient No conductivity with the applied part
For use in environments where no flammable anesthetics and/or flammable cleaning agents
are present; use a non-acetone based disinfectant wipe (with less than 17% alcohol content)
or a cloth to wipe the exterior surfaces of the NOMAD Pro 2 and charger. Do not use cleaners
intended for hard surfaces, since certain chemical combinations may deteriorate the NOMAD
Pro 2 plastic prematurely.
Electrical
Rechargeable lithium batteries 22.2V nominal; 25.2V maximum, 1.25A/hr
Low battery alert set point Any cell (of the 6) <3.5V
Battery current at 2.5mA, 60kVp output 12.5A
Typical energy input 150W
X-ray Controls and Generator
Exposure time range 0.02–1.00 sec. (in 0.01 second increments)
Maximum duty cycle 1:60 (one 1 second exposure every 60 seconds)
Minimum permanent filtration 1.5mm Al (0.8mm glass, 0.5mm Al, 0.2mm
plastic cap)
