GB - 11
.
Check Function of Dual Handle
Interlock
Without the engine running, press down
(engage) both clutch levers. Release
attachment clutch lever. Attachment clutch
should remain engaged until traction clutch
lever is released, then both clutches must
disengage. If they do not, contact your Dealer
for repairs.
Check Tire Pressure
Check tire pressure and adjust to the
pressure listed on tire sidewall.
Check Auger Gearcase Oil
Check oil level in auger gearcase (see Check
Auger Gearcase on page 21).
Check Engine Crankcase Oil
IMPORTANT: The engine is shipped with
5W-30 oil in crankcase. Refer to Engine
Manual for detailed instructions.
Fill Engine Fuel Tank
See Filling Fuel Tank on page 17.
Check Function of all Controls
Ensure unit runs and performs properly. Refer
to Operation.
Run-in Attachment Belt
1. Start unit in a well-ventilated area
according to Starting and Shut Off on
page 18.
2. Engage attachment clutch lever and run
attachment for about 15 minutes.
3. Stop unit, wait for all moving parts to
stop, and remove spark plug wire.
4. Adjust belt finger, if necessary. See
Replace Attachment Drive Belt on
page 25.
5. Adjust clutch idler according to
Attachment Clutch/Brake Adjustment on
page 27.
CAUTION: Avoid injury! Explosive
separation of tire and rim parts is
possible when they are serviced
incorrectly:
• Do not attempt to mount a tire
without the proper equipment
and experience to perform the
job.
• Do not inflate the tires above
the recommended pressure.
• Do not weld or heat a wheel
and tire assembly. Heat can
cause an increase in air
pressure resulting in an
explosion. Welding can
structurally weaken or deform
the wheel.
• Do not stand in front or over
the tire assembly when
inflating. Use a clip-on chuck
and extension hose long
enough to allow you to stand
to one side.
Figure 9
1. Upper Mounting
Hole
2. Snap Fitting
3. Rubber Seal
Cap
4. Hairpin
5. Washer
6. Cable Eye
2
1
3
4
6
5
OS8066
