Page #12 background imageLoading...
Page #12 background image
GB - 12
1. Attachment Clutch Lever
2. Speed Selector
3. Traction Drive Clutch Lever
4. Chute Crank
5. Muffler Guard
6. Manual Discharge Chute Deflector
(920012, 013, 014)
7. Discharge Chute
8. Impeller
9. Auger
10. Scraper Blade
11. Auger Gearcase
12. Clean-out Tool
13. Skid Shoe(s)
14. Axle Lock Pin
15. Belt Cover
16. Handlebars
17. Headlight (920012, 014, 015)
18. Remote Deflector Control (920015)
CONTROLS AND FEATURES
Figure 10
1
2
3
4
5
6
7
8
9
10
11
12
13
15
14
16
17
18
OS8070
OS8072

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Ariens Compact 24 and is the answer not in the manual?

Ariens Compact 24 Specifications

General IconGeneral
Clearing Width24 inches
Engine Power208cc
Stage TypeTwo-stage
Start TypeElectric start
Fuel TypeGasoline
Engine Displacement208cc
Drive TypeWheel Drive
Fuel Tank Capacity2.9 quarts
Intake Height20 inches
Auger MaterialSteel
Throw DistanceUp to 40 ft
Chute ControlRemote
Transmission6 forward, 2 reverse
Drive SystemDisc-O-Matic
