Ariens Compact 24 User Manual

GB - 34
SPECIFICATIONS
Model Number 920012 920013
Description Compact 22 Compact 22
Engine Ariens
OHV
Subaru SX17
Snow Power OHC
Gross Torque* - ft-lbs (N-m) 9.5 (12.88) –
*Engine output stated in gross torque per SAE J1940 as rated by engine manufacturer.
Displacement - in. (cc) 12.7 (208) 10.31 (169)
High Idle - RPM (min) 3600 ± 100
Electric Start 120V
Fuel Tank Capacity - qt (Liters) 2.7 (2.55) 2.9 (2.7)
Headlight Yes No
Chute
Chute Rotation Angle 205°
Rotation Control 2.5X Quick Turn
Deflector Control Manual
Auger
Snow Clearing Width - in. (cm) 22.0 (55.8)
Gear Case Aluminum
Auger Diameter - in. (cm) 11.0 (27.9)
Impeller
Impeller Diameter - in. (cm) 12.0 (30.5)
Impeller Speed (RPM) 1190
Impeller Tip Speed
- ft/sec (m/s) 3738 (1139)
Drive
Blower Drive HA Belt
Drive System
Disc-O-Matic
®
Speeds 6 Forward and 2 Reverse
Axle Control Pin-Lock
Pneumatic Tires - in. (cm) 13 x 4-6 13 x 4-6
Size and Weight
Length - in. (cm) 51.9 (131.8) 51.9 (131.8)
Height - in. (cm) 44.3 (112.5) 44.3 (112.5)
Width - in. (cm) 24.4 (62) 24.4 (62)
Weight - lbs (Kg) 172 (78) 172 (78)

Ariens Compact 24 Specifications

General

Clearing Width	24 inches
Engine Power	208cc
Stage Type	Two-stage
Start Type	Electric start
Fuel Type	Gasoline
Engine Displacement	208cc
Drive Type	Wheel Drive
Fuel Tank Capacity	2.9 quarts
Intake Height	20 inches
Auger Material	Steel
Throw Distance	Up to 40 ft
Chute Control	Remote
Transmission	6 forward, 2 reverse
Drive System	Disc-O-Matic
