ARIESAUTOMOTIVE.COM • NEED ASSISTANCE? • 800.798.0813 • 25630AB-INS-RB • PAGE 4
Step 9
With the 8mm fasteners reinstalled,
completely tighten all the hardware.
With the hardware tightened, re-install
the louvered panel inside the carrier.
Step 10
Thread the third brake light wire back
through the access hole and reinstall
the grommet removed in step 3.
Step 11
Open the rear door to access the wiring
panel and reconnect the brake light.
With the wire reconnected, replace the
louvered panel in the inside of the door
removed in step 2.
Step 12
With the carrier reinforced, the
extension bracket can now be installed.
Place the spare tire extension bracket
over the three factory lugs and secure it
with the supplied 1/2" - 20 nylock nuts.
Ensure all the hardware is completely
tight before reinstalling the spare tire.
