Mounting the Thin Client
Desktop mounting
The AP-3500-E01 Office Thin Client can be directly placed on a shelf or table by using
desktop stand base(supplied with the unit).
Please follow the steps shown in the diagram below:
Step1.
Place the bottom side ofAP-3500-E01 O󰀩ce Thin Client within the place on the
desktop stand base where there are four mounting clips.
Step2.
SlidetheDesktopstandbasealongwiththeAP-3500-E01O󰀩ceThinClientbottom
sideuntilthefourmountingclipsonthestandbasermlylocktheunit.
