Ariston CLIMA MANAGER - Display Layout

47
ITGB
Man/Timer Menu
0 2 4 6 10 12 14 16 18 20 22 24h8
019
20 0
12 0
16 30Mo 26 09 2006
019
019
012
3016
0 2 4 6 10 12 14 16 18 20 22 24h8
019
Display
Press the display button to select one of the
5 display modes.
Each time it is pressed the display changes:
- complete display
(all information displayed)
- room temperature only
- outdoor and room temperatures
(when the outdoor sensor is installed)
- schedule indication
- room temperature and operating status
Legend:
A. boiler operating mode:
Summer (
)
Winter (
)
Heating only (
)
O (boiler switched o )
B. operating status indication:
daytime programming (
)
night-time programming ( )
daytime manual (
)
night-time manual (
)
O ( ) anti-freeze enabled
C.  ame detected indication
D. set room temperature
E. detected room temperature
F. current date and time
G. outdoor temperature indication
H. auto function enabled indication
I. heating periods schedule
L. time indication
product description
A
B
D
E
F I
I
D
B
E
D
G
L
G
C
H
