Ariston MICROCOMBI 23 MFFI Installation And Servicing Instructions

40
6.5.6 Removing the expansion vessel
1.
Release nuts “G1” and remove the gas pipe (FIG. 6.44);
2. Release nut “H1” (FIG. 6.45);
3. Remove back-nut “I1” (FIG. 6.46);
4. Remove the expansion vessel (FIG. 6.47).
6.5.5 Removing the pressure gauge
1.
Remove the U-clip “F1” (FIG. 6.42)
2. Remove the pressure gauge coupling (FIG. 6.42);
3. Push the pressure gauge through the control panel
from the rear (F
IG. 6.43).
FIG. 6.44
F1
FIG. 6.43
G1
H1
FIG. 6.45
FIG. 6.46
FIG. 6.47
G1
I1
FIG. 6.42
