6.5.7 Removing the overheat thermostat
1.
Disconnect the overheat thermostat electrical
connections “J1” (FIG. 6.48);
2. Then remove the thermostat from its mounting by
releasing the securing clip (F
IG. 6.49 /6.50).
6.5.8 Removing the heating temperature sensor
(N.T.C.)
1.
Pull off the electrical connector and unscrew the sensor
probe using a suitable spanner (FIG. 6.51).
FIG. 6.48
FIG. 6.49
6.5.9 Removing the D.H.W. temperature sensor
(N.T.C.)
1.
Pull off the electrical connector and unscrew the sensor
probe using a suitable spanner (FIG. 6.52).
J1
FIG. 6.51
FIG. 6.50
FIG. 1.52
