EXTERNAL UNIT
The external unit supplied is one of the following models:
• NIMBUS EXTERNAL UNIT 04 kW
• NIMBUS EXTERNAL UNIT 06 kW
• NIMBUS EXTERNAL UNIT 08 KW
EXTERNAL UNIT
Kg
04 kW 56
06 kW 58
08 kW 68
908
821
326
350
Dimensions and Weights
1’M
1’M
1/2’F
87
60
40
404
350
398
AB
LM
CDE F G
H
I
41
93
145
197
249
303
357
109
207
HYBRID MODULE
Dimensions and Weights
A. Heating delivery G ¾” M
B. Domestic hot water delivery G ½” M
C. GAS inlet G ¾” M
D. Cold water inlet G ½” M
E. System return G ¾” M
F
. Hot/cold water delivery from external unit G ¾” M
G. Return to external unit G ¾” M
H. PV signal connection wire clamp
I. EDF signal connection wire clamp
L. Low voltage connections core hitch
M. High voltage connections core hitch
Kg
HYBRID MODULE 7
