Ariston NIMBUS EXTERNAL UNIT 04 kW User Manual

/ 75
HYBRID MODULE data plate
1
2
3
4
5
9
10 11
MAX MIN
Legend:
1. Brand
2. Manufacturer
3. Model - Serial no.
4. Commercial code
5. Certifi cation no.
9. Electrical data
11. Maximum heating pressure
External unit data plate
1
2
3
45
9
10
11
6
7
8
12
13
14
15
16 17
Legend:
1. Type-approval
2. Certifi cation
3. Model
4. Certifi cation no.
5. Electrical data
6. Serial number
7. Maximum electrical power
8. Protection index
9. Grade of protection of the electrical system
10. Maximum refrigeration circuit pressure
11. Minimum refrigeration circuit pressure
12. Nominal heating performance
13. Water circuit maximum temperature/pressure
14. Refrigerant type - refrigerant fi lling
15. Refrigeration circuit oil type
16. Place of manufacture
17. Brand

Ariston NIMBUS EXTERNAL UNIT 04 kW Specifications

General

Brand	Ariston
Model	NIMBUS EXTERNAL UNIT 04 kW
Category	Heat Pump
Language	English
