MENU SUB-MENU PARAMETER DESCRIPTION RANGE FACTORY SETTINGS
12 12 1 HP water fl ow temp only reading (°C)
12 12 2 HP water return temp only reading (°C)
12 12 3 HP Evaporator temp only reading (°C)
12 12 4 HP Suction temp only reading (°C)
12 12 5 HP Discharge temp only reading (°C)
12 12 6 HP condenser outlet temp only reading (°C)
12 12 7 Flow Switch only reading (°C)
12 12 8 TEO only reading (Hz)
12 13 HP Diagnostics - 2
12 13 0 Heat Pump Mode
OFF
Stand by
Cooling
Heating
Booster Heating
Booster Cooling
Rating Heating Mode
Rating Cooling Mode
Freeze Protection
Defrost
High Temperature Protection
Timeguard
System Fail
Hard System Fail
Pump Down
Soft Fail Mode
only reading
12 13 1 HP Error only reading
12 13 2 Safety thermostat Close - Open only reading
12 13 3 Flowmeter only reading
12 13 4 Flow Switch Close - Open only reading
12 13 5 Inverter shut o protection only reading
12 13 6 Evaporator Pressure P only reading
12 13 7 Condenser Pressure P only reading
12 14 HP Diagnostics - 3
12 14 0 Inverter Capacity only reading
12 14 1 HP Actual Compressor frequency only reading
12 14 2 HP Set Compressor Modulation only reading
12 14 3 Electric Heater 1 OFF - ON only reading
12 14 4 Main circulator status OFF - ON only reading
12 14 5 Measured rpm fan 1 only reading
12 14 6 Measured rpm fan 2 only reading
12 14 7 Expansion valve only reading
12 15 HP Diagnostics - 4
12 15 0 compressor on/o OFF - ON only reading
12 15 1 compressor preheating OFF - ON only reading
12 15 2 current fan 1 status OFF - ON only reading
12 15 3 current fan 2 status OFF - ON only reading
12 15 4 4way valveheat/cool Heat - Cool only reading
12 15 5 Base Panel Heater Status OFF - ON only reading
12 15 6 Compressor Phase Current only reading
12 16 EM Diagnostics - 1 Input
