Aritech AS280G3 User Manual

P/N PAK200953-ML • REV F • ISS 12JAN23 5 / 16
Fault finding
Table 5 : Fault symptoms and actions
Symptom
Fault
Action
Sounder activated in
non-alarm condition
and Tamper shows
at panel
Cover not closed
correctly
Check cover closed
and screw secure.
BL+ not pulled up to
ALIM+ in standby mode
Fit pull up resistor to
BL+ at control panel.
See Figure 3, item 5.
Sounder stops
after 5 s
Incorrect timer link
setting
Set correct timer
jumper links.
Cannot SET control
panel (due to
sounder Tamper)
Tamper output open
due to ING input still
connected to ALIM+
Disconnect ING from
ALIM+ in sounder or
set control panel
programmable output
low.
Tamper Source AP(S)
not connected to ALIM−
for single sounder or to
Tamper Return AP(R)
for cascaded sounders
Refer to connection
diagrams for single
and cascaded
sounders (Figures 3
and 4)
Total resistance of
Tamper circuit too high
for multiple sounder
installations
Reduce number of
cascaded sounders
on one Tamper loop
Tamper switch not
closed
Check cover and
ensure rear Tamper
break intact
Ring trigger signal
(BL+) disconnected
(floating)
Ensure BL+ pulled up
to ALIM+ in standby
mode
Fault output open
Battery not connected
Check battery
connections to
terminal block
Battery faulty or voltage
low
Replace battery
Battery charger faulty
Return unit to
manufacturer
Audible alarm stops
before timeout.
Battery level very low
Recharge battery
Clicking noise from
sounder during
commissioning
See Table 3 on page 4.
Disposal of product at end of life
This product falls within the scope of EU Directives
2012/19/EU Waste Electrical and Electronic Equipment
(WEEE) and 2013/56/EU (Battery). At the end of life, the
product must be separated from the domestic waste stream
and disposed via an appropriate approved WEEE disposal
route in accordance with all national and local regulations.
Before disposal of the product, the battery must be removed,
and disposed of separately via an appropriate approved
battery disposal route in accordance with all national and local
regulations. Package used batteries safely for onward
transport to your supplier, collection point or disposal facility.
WARNING: Risk of fire or explosion if exposed battery wires
are allowed to touch.
See “Specification” below for battery type information. The
battery is marked with the crossed-out wheelie bin symbol,
which may include lettering to indicate cadmium (Cd), lead
(Pb), or mercury (Hg).
Specification
Sound output
101.5 dBA at 1 m
Frequency range
2430 to 3250 Hz
Power supply
9.0 to 15.0 VDC, 13.8 VDC nominal
Current consumption
1.6 A max. from battery
Cut-off timer
Selectable 5 seconds, 90 seconds,
3 minutes, 15 minutes. 5 s cut-off time
option intended for installation purposes
only.
Battery
12 V 2.2 Ah SLA. Battery recharge in less
than 24 hours (following 10 x 3 minutes
sounding)
Note: The siren is specified to function with
the Aritech BS122N battery, and it is
essential that this battery is used.
Battery Low Voltage
detection
10.9 V nominally
Standalone working time
(battery only)
60 h
Tamper detection
- Combined cover and rear switch with
break out.
- Cut-line detect (Ring trigger signal)
Tamper output
Volt free contact (when the jumper is cut),
maximum 16 Ω resistance
Max 100 mA current rating
Fault output
Volt free contact, maximum 16 Ω resistance
Max 100 mA current rating
Sound trigger input
BL+ <1 V
Strobe trigger input
FL+ <2.5 V
Dimensions (W x H x D)
187 x 167 x 47 mm
Weight
1.34 kg without battery
Fixings
M5 screws (5X)
Cover material
Steel
Backplate material
Steel
Other materials
ABS
Protection level
IP30, IK07
Operating temperature
−10 to +55°C
Storage temperature
−10 to +55°C
Relative humidity
<95% noncondensing
Regulatory information
Manufacturer
PLACED ON THE MARKET BY:
Carrier Fire & Security Americas Corporation Inc.
13995 Pasteur Blvd
Palm Beach Gardens, FL 33418, USA
AUTHORIZED EU REPRESENTATIVE:
Carrier Fire & Security B.V.
Kelvinstraat 7, 6003 DH Weert, Netherlands
