2.5 Control panel
2.5.1. Components
Typhoon
2 4
5
6
3
1
Figure 2. Control panel
1. Yellow: Process running
2. Green: Process complete
3. Red: Disinfection not achieved or other error code F
4. Display
5. Open/close door.
6. Sensor to open/close door and to start preselected
program
2.5.2. Functions
Note! Disinfection is not included in the rim ushing
program.
Button/lamp Function
When the yellow light comes on: The machine is
running a program.
The temperature/A0-value/time and cleaning
phase can be seen on the display.
When the green light comes on: The program
is complete. The green lamp goes out when the
door is opened and the maximum temperature of
the process shows on the display.
When the red light comes on: The machine has
not reached the disinfection temperature or
another error has occurred (Error code F).
Sensor to open/close door and to start
preselected program
Open/close door
