2. TECHNICAL SPECIFICATIONS
Input supply:
Supply voltage:
20VAC±10%
Max. Power consumption:
10W (control circuit) + Motor power
Supply protection:
Short-circuit protection (8A)
Motor outputs:
Motor voltage:
24VDC
Motor output power:
Max. 200W (8A)
Motor control type:
4-region motor control
Motor protection:
Motor output overload and short circuiting protection
Encoder inputs:
Encoder type:
Incremental (2-channel incremental encoder)
Encoder resolution:
Any model between 100 pulse and 2048 pulse
Encoder voltage:
5V DC
Note: Encoder is not included
Output signals:
Outputs for control panels:
Door open signal
Door closed signal
Door obstruction or photocell detected signal
Output type:
with relay contact output
3A @ 250V AC or 30V DC
Input signals:
Door control & speed signals:
(Opto-coupled)
Open signal
Close signal
Low speed
High speed
Other inputs:
Photocell & obstruction signal
Car is at floor level signal
1 programmable input (reserved)
Input type:
Activated with 24VDC
Battery connection:
Battery voltage:
2 pieces 12V batteries
Internal battery charge:
Included
Battery protection:
- With fuse
- Battery over-discharge protection with sleep mode operation.
User interface:
Standard interface:
2-digit 7-segment display and 4 keys
Optional interface:
KM-20 Keypad
Warning sound:
With buzzer
Language options:
Turkish, English, Greek
Mechanical features:
Dimensions:
116 x 160 x 50 mm (width x length x height)
Working capability:
Door opening:
0.5m - 3m
Door opening velocity:
Max. 50 cm/s
