14.2. DOOR OPENING SETTINGS
Adjust door opening settings by referring to Figure-14.
OPENING SPEED
The maximum opening speed
OPENING SLOW SPD
Opening slow speed when door reaches to the opening rubber stopper
OPEN RAMP
LENGHT
The opening distance while door accelerates (from slow speed to
opening speed) and while door decelerates (from opening speed to
slow speed)
OPEN SLOW AREA
The opening distance with slow speed up to the opening rubber stopper
SKATE OPEN SPEED
Skate opening speed
SKATE ZONE
The distance that is required for skate to fully open
Figure-14: Door opening travel curve
