ARKEL Elektrik Elektronik Ltd. Şti. www.arkel.com.tr
ARKEL 45 KM-20
On the manual operation screen, door can be opened and closed by the user via keypad.
Note: On this screen, the door control signals (open, signal etc.) are ignored. If no operation
will be done on this screen in 60 seconds, controller will exit this screen and automatically
switch back to normal operation.
The information of door opening-closing time is monitored in the counter screen.
MANUEL MOVMENT
OPEN CLOSE
Figure-12: Manuel operation screen
Door closes while holding
down the right key
Door opens while holding
down the left key
OPEN/CLOSE COUNT
000000389
Figure-12.1: Counter screen
Total opening/closing time
