Armstrong 6100 - Page 40

40
Item
No.
Electrical Compartment
and Front Panel
Part No.
31 Label Front Panel With Keypad D10876
16 Emergency Stop Button D10866
1Main PCB For HC-600
0D
8025
-Wire Harness For HC-650
0D
10874
-Wire Harness For HC-670
0D
10875
32a LCD Display For HC-600
0D
8024
32b Display Driver Boar
dD
8026
14 Fan DC24 with 2 Cove
rD
10869
12 Terminal Block #000 Wire B5607
11 Definite-Purpose Contactor 50AMPB2721
6Fuse 3AMP A10718
7Fuse 1A D11114
5Fuse Block 3AMP A8649
13 Module Power Din 15KW HC-6000B5092
13 Module Power Din 15KW HC-6000B5151
8Trans 208/240/380/480-24V B5605
8Trans 600V-24V B5604
3Fuse Holder 30 AMP HC-6000 B4039
3Fuse Holder 30 AMP HC-6000 A21882
4Fuse 30 AMP HC-600
0B
4040
4Fuse 40 AMP HC-600
0A
21883
4Fuse 50 AMP HC-600
0A
21884
Item
No.
Water Compartmen
tP
art No.
-PVC Tubing 5/8” A7618A
-Clap Hose Flat .63 Oliv
eB
2716-11
-Hose Clamp, Minerature, Worm B2911-8
25 Fill Valv
eD
10867
25 Fill Valve SS DI/R
OD
10721
21 Tubing Rd 7/8 Old Silico
nA
19699
23 Clamp Hose Flat .8
8B
2716-18
22 Tee Barbed HDPE 5/
8A
23237
24 Elbow Barbed 5/8A10579
27 Fill Cup For Series HC-6000RDHC6000-001
27 Bracket For Fill CupB2929
28 Bracket Liquid Level B5135
28 Brkt HC-6000 Liquid Level A22010
20 Drain Valv
eD
10868
18 Drain Cu
pD
10862
17 Reducing Bushing Brass 1”-1/2
”D
11443
30 Probe Level Assy Ta
pC
4561
29 Container For Probe Level C4559
- Long Probe For Water Level
(Low and Common) B5268
-Short Probe For Water Level (High) B5269
-Reducing Bushing For Water Leve
lA
21391
-Float Level Assy DI/R
OC
4560
-Float Switch DI/ROB5139
Item
No.
Water Compartmen
tP
art No.
26
S-assy Ionic Bed HC-6000
(14 required for Model HC-6500 and HC-6700)
B5213
- Thermistor 5 KOHM With Wire (Aquastat)D10870
HC6500/6700 Repair Parts
