Heating Elements 6100/6300
TC=Thermocouple
HC-6100
Voltage
3kW 3kW DI
Without TC
2PCS/Unit
With TC
1PCS/Unit
Without TC
2PCS/Unit
With TC
1PCS/Unit
208 B5808-1 B5809-1 B5810-1 B5811-1
240 B5808-2 B5809-2 B5810-2 B5811-2
380 B5808-1 B5809-1 B5810-1 B5811-1
480 B5808-3 B5809-3 B5810-3 B5811-3
600 B5808-4 B5809-4 B5810-4 B5811-4
HC-6100
Voltage
9kW 15kW
Without TC
2PCS/Unit
With TC
1PCS/Unit
Without TC
2PCS/Unit
With TC
1PCS/Unit
208 B5047-1 B5048-1 B5043-1 B5044-1
240
B5047-2 B5048-2 B5043-2 B5044-2
380 B5047-1 B5048-1 B5043-1 B5044-1
480 B5047-3 B5048-3 B5043-3 B5044-3
600 B5047-4 B5048-4 B5043-4 B5044-4
HC-6100 DI
Voltage
9kW 15kW
Without TC
2PCS/Unit
With TC
1PCS/Unit
Without TC
2PCS/Unit
With TC
1PCS/Unit
208 B5049-1 B5050-1 B5045-1 B5046-1
240 B5049-2 B5050-2 B5045-2 B5046-2
380 B5049-1 B5050-1 B5045-1 B5046-1
480 B5049-3 B5050-3 B5045-3 B5046-3
600 B5049-4 B5050-4 B5045-4 B5046-4
HC-6300
Voltage
18kW 30kW
Without TC
5PCS/Unit
With TC
1PCS/Unit
Without TC
5PCS/Unit
With TC
1PCS/Unit
208 B5047-1 B5048-1 B5043-1 B5044-1
240 B5047-2 B5048-2 B5043-2 B5044-2
380 B5047-1 B5048-1 B5043-1 B5044-1
480 B5047-3 B5048-3 B5043-3 B5044-3
600 B5047-4 B5048-4 B5043-4 B5044-4
HC-6300 DI
Voltage
18kW 30kW
Without TC
5PCS/Unit
With TC
1PCS/Unit
Without TC
5PCS/Unit
With TC
1PCS/Unit
208 B5049-1 B5050-1 B5045-1 B5046-1
240 B5049-2 B5050-2 B5045-2 B5046-2
380 B5049-1 B5050-1 B5045-1 B5046-1
480 B5049-3 B5050-3 B5045-3 B5046-3
600 B5049-4 B5050-4 B5045-4 B5046-4
