Page 27 of 36
Keypad Operating Instructions, cont.
Reg Run Values Read/Write Units Values
10 Setpoint Temperature RO 0.1°C
11 Setpoint Position RO 0.1°C
12 Modbus Setpoint Temperature RW 0.1°C 0 - 100
13 Modbus Setpoint Position RW 0.1°C 0% - 100%
14 Analog In Setpoint RO 0.1°C / 0.1% Dependent on
15 Control Variable RW enum 0 = Temperature, 1 = Position
16 Setpoint Source RW enum 0 = Local, 1 = Analog, 2 = Modbus
17 System of Measurement RW enum 0 = Imperial, 1 = Metric
19 Current Temperature RO 0.1°C 0 - 100
20 Current Position RO 0.1°C 0% - 100%
21 Override Handle Status RO bool 0 = Engaged, 1 = Disengaged
Reg Advanced Settings Read/Write Units Values
50 Gains Multiplier RW 0.1%
51 Angle Min RW 0.1° rotation 0°-355° rotation
52 Angle Max RW 0.1° rotation 0°-355° rotation
53 Control Angle Start RW 0.1° rotation 0°-355° rotation
56 Control Angle Stop RW 0.1° rotation 0°-355° rotation
57 Direction RW bool 0 = CW, 1 = CCW
58 Slow Zone Offset RW 0.1° rotation 2 -15° rotation
59 Reverse Gains RW bool 0 = Standard, 1 = Reverse
60 Zero Angle Offset RW 0.1° rotation
61 Fault Position RW 0.1° rotation 0°-355° rotation
62 Lock Enabled RW bool 0 = Enabled, 1 = Disabled
63 Lock Pin RW Integer 0 - 9999
Reg Flow Read/Write Units Values
80 State RO bool 0 = Engaged, 1 = Disengaged
81 Position Override RW bool 0 = Enabled, 1 = Disabled
82 Position Override Value RW 0.1°C 0 - 100
83 Temperature Override RW bool 0 = Enabled, 1 = Disabled
84 Temperature Override Value RW 0.1°C 0 - 100
85 Gains Override RW bool 0 = Enabled, 1 = Disabled
86 Gains Override Value RW 0.1°C 25% - 175%
87 Aux Input Direction RW bool 0 = NO, 1 = NC
Reg Analog Read/Write Units Values
100 Analog Commands RW bool 0 = Engaged, 1 = Disabled
106 Loop Out Option RW bool 0 = Auto, 1 = Temperature, 2 = Position
107 Loop Out Current RO
Reg Fault Indicators Read/Write Units Values
151 E1: Critical Error RO bool 0 = Normal, 1 = Fault Present
152 E2: Temperature Probe RO bool 0 = Normal, 1 = Fault Present
153 E3: Voltage RO bool 0 = Normal, 1 = Fault Present
154 E4: Analog Signal RO bool 0 = Normal, 1 = Fault Present
5.5 - Modbus Registers
