Array electronic 372 Series User Manual

60
setting menu; use , keys to select CV mode. Press
key to confirm and exit the mode selection and parameter setting
menu.
5
Press
key to turn on the load.
0.000V 0.000A
0.000V sCV ON
For the above operating procedures, the corresponding SCPI commands should be:
INP:SHORT ON ；Sets the load to short circuit
MODE CV ；Sets the mode
INP ON ；Turns on the load
4.14.3 Von Point/Von Latch
Example: Set the Von Latch to Off; set Von Point to 1V; turn on the load; This example
implements the automatic turning on/off of the load`s input, which simplifies the test operations
greatly. The detailed operations are shown below:
Procedures Operation Descriptions Display
1
Press
key to enter into the main menu.
Load Default：
Yes *No
2
Use
key to select the menu item “Von Latch”; use the knob
or
key to select the parameter “Off”. Press key to
confirm.
Von Latch：
*On Off
3
Use
key to select the menu item “Von Point”; use Entry keys
or the knob together with
, keys to input the voltage
value. Press
key to confirm.
Von Point：
1.000
V
4
Press
key to exit the main menu.
0.000V 0.000A
0.000
A CCH OFF
5
Press
key to turn on the load.
0.000V 0.000A
0.000
A CCH ON
For the above steps, the corresponding SCPI commands should be:
INP: LATC OFF ；Disables the Von Latch
INP: LATC:VOLT 1 ；Sets the Von voltage point to 1V
INP ON ；Turns on the load
4.14.4 Current Limit in CV Mode
Example: Set the load to CV mode; set the voltage value to 2V; set the current limit value in CV
mode (
CV Curr Limit) to 20A; turn on the load. The detailed operations are shown below:
Procedures Operation Descriptions Display
step1 Set the load to CV mode, and set the voltage value to 2V (please 0.000V 0.000A
