ARRI ALEXA Mini Quick Guide

Connectors 25
7.3.1 Preparing a USB memory stick
2
3
1
USB memory sticks for the ALEXA Mini must have a specific folder structure which
can be created with the camera.
1. To prepare a USB memory stick: Open the media lid (1).
2. Connect a FAT-formatted USB stick (3) to the camera (2).
3. From the home screen, navigate to Menu > Media > Prepare USB medium.
4. Press CONFIRM to prepare the folder structure.
5. The USB stick (3) is now ready for use with the camera.
6. Note: To avoid file corruption, never remove the USB stick during write access.
7. You can remove the stick from the camera without unmounting.

ARRI ALEXA Mini Specifications

General

Sensor Type	ALEV III CMOS
Dynamic Range	14+ stops
Recording Formats	ARRIRAW, ProRes
Power Input	10.5-34 V DC
Base Sensitivity	EI 800
Lens Mount	PL mount
Weight	2.3 kg
ISO Range	160 to 3200
Frame Rates	0.75 - 200 fps (depending on recording format and sensor mode)
Dimensions	185 mm x 125 mm x 140 mm
Power Consumption	Approx. 50 W
Outputs	HD-SDI
Sensor Size	Super 35 format
