ARRI ALEXA Mini Quick Guide

MVF-1 controls 41
10.2.3 VF1 & VF2 user buttons
1
► Via the camera menu, you can assign a function to both VF-1 and VF-2 buttons
(1). For details, see the user manual.
10.2.4 PLAY button
1. Press PLAY (1) for one second to see the last clip of the active CFast 2.0 card.
2. To leave playback: Press PLAY (1) for one second.
3. Or: Press the EXIT screen button.
4. To select other clips, use the on-screen navigation. For details, see the User
Manual.

ARRI ALEXA Mini Specifications

General

Sensor Type	ALEV III CMOS
Dynamic Range	14+ stops
Recording Formats	ARRIRAW, ProRes
Power Input	10.5-34 V DC
Base Sensitivity	EI 800
Lens Mount	PL mount
Weight	2.3 kg
ISO Range	160 to 3200
Frame Rates	0.75 - 200 fps (depending on recording format and sensor mode)
Dimensions	185 mm x 125 mm x 140 mm
Power Consumption	Approx. 50 W
Outputs	HD-SDI
Sensor Size	Super 35 format
