ARRI ALEXA Mini Quick Guide

28 Lens mount/filters
8 Lens mount/filters
1
1 Lens mount (here: titanium
PL)
Cooke /i support
The camera supports the Cooke /i protocol for lenses running FW versions according
to the following table.
Lens type FW version
S4 /i Prime lens (10-bit) 0.29 or higher
S4 /i Prime lens (12 bit) 0.39 or higher
S4 /i Zoom lens (10 bit) 1.29 or higher
S4 /i Zoom lens (12 bit) 1.39 or higher
The FW version can be retrieved from the lens with the Cooke Viewer Lens Display
program. For detailed info, please contact Cooke Optics directly.
8.1 ND filter module
NOTICE
ALEXA Mini uses FSND (Full Spectrum Neutral Density) filters, which are linear
across the full spectrum of the camera sensor. This prevents artifacts from infrared
wavelengths and the need for additional IR filters.
The camera contains an internal ND filter module, consisting of ND 0 (Clear), 0.6, 1.2
and 2.1 filters. The filters can be operated via user buttons, MVF-1, web remote, or
WCU-4.

ARRI ALEXA Mini Specifications

General

Sensor Type	ALEV III CMOS
Dynamic Range	14+ stops
Recording Formats	ARRIRAW, ProRes
Power Input	10.5-34 V DC
Base Sensitivity	EI 800
Lens Mount	PL mount
Weight	2.3 kg
ISO Range	160 to 3200
Frame Rates	0.75 - 200 fps (depending on recording format and sensor mode)
Dimensions	185 mm x 125 mm x 140 mm
Power Consumption	Approx. 50 W
Outputs	HD-SDI
Sensor Size	Super 35 format
