Technical Data are subject to change without notice.CAMERA DIMENSIONS – Version 2013-04
ALEXA Plus with XR Module
ALEXA Plus Length Width Height Weight
Body, XR Module 332 mm - 12.95” 184.6 mm - 7.27” 158 mm - 6.22” 7.3 kg - 16.1 lb
Body, XR Module, Camera Center Handle (CCH-1), Electronic Viewfinder EVF-1
384 mm - 15.12” 274 mm - 10.8” 224 mm - 8.82” 8.7 kg - 19.2 lb
Camera Right Image Plane
Camera Front Optical Center
Optical Center
M6 (3.5mm deep)
85 mm
3.35”
128.8 mm
5.07”
17.6 mm
0.7”
223.8 mm
8.81”
66 mm
2.6”
157.8 mm
6.21”
102.8 mm
4.05”
171.2 mm
6.74”
120,3 mm
4.74”
59.4 mm
2.34”
10 mm
0.39”
40 mm
1.58”
76.2 mm
3”
264 mm
10.4”
UNC 3/8“–16 (10 mm deep)
UNC 3/8“–16 (10 mm deep)
199 mm
7.84”
ø 15 mm ø 15 mm
30 mm
1.18”
30 mm
1.18”
14.8 mm
0.58”
