*XT = function available on ALEXA XT/XR only *ANAMORPH = requires Anamorphic Desqueeze License *DNxHD = requires DNxHD License *HS = requires
High Speed License *PLUS = ALEXA PLUS only *PLUS 4:3 = ALEXA PLUS 4:3 only *STUDIO = ALEXA STUDIO only *M = ALEXA M only *NON XT = only
available on ALEXA „Classic“ cameras *OG = settings and values introduced by the Open Gate Mode are not covered by this overview.
SUP 9.0
PLAY
FRAME GRAB TRIGGER
save Framegrab to SD Card
TIMECODE screen
SET TC (SET TO TIME/RESET/MANUAL)
OPTIONS
Timecode Options >>
Source (Int TC/Ext LTC)
Mode (Rec run/Free Run)
Generator (Regen/Jam Sync)
User bit source (Internal/LTC in UB)
USERBITS (set Userbits)
PROJECT (Menu > Project)
PLAYBACK screen
start Playback of last clip (press wheel or PLAY 2x on operator’s side)
+/- 10%
CLIPLIST
OPTIONS
PLAY Options >>
Clip end action (Pause/Loop)
Show frame lines (On/Off)
Status info on MON OUT (On/Off)
STEPSIZE (1 frame/1 second)
CIRCLE CLIP
INFO
SYSTEM INFORMATION screen
LIVE INFO
SAVE TO SD
VERSION
MEDIA INFO
SYSTEM
FPS INFO
GRAB
TC
LOCK
BUTTON LOCK
locks HOMESCREEN,MENU, PLAY, TC and INFO;
also locks the buttons on EVF and WRS*
ALEXA (XT) PLUS & STUDIO
!
