ELECTRONIC VIEWFINDER EVF-1
EVF menu
Brightness (0-5)
Rotate Image (On/Off)
Smooth Mode (On/Off)
Surround View (On/Off)
Surround Mask (Black line/Color Line/Mask 25%/50%/75%)
Status Info (On/Off)
Frame Lines (On/Off)
Select Frame Lines 1 (choose from list)
Select Frame Lines 2 (choose from list)
Center Mark (Off/
Medium dot/Small dot/Cross)
User Rectangles (Off/Rect 1/Rect 2/Rect 1&2)
Edit User Rectangles (only when User Rectangles active)
Frame Lines Color (Red/Green/Blue/Yellow/Black/White)
Frame Lines Intensity (1-4)
CAM
EVF
MIRROR CONTROL*
ALEXA (XT) STUDIO
switch to VIEW-mode (operator sees an image)
press VEW + GATE for spinning mirror
switch to GATE-mode (sensor & all video outs “see” an image)
press GATE + VIEW spinning mirror
VIEW
GATE
FPS
set sensor speed (0.75 fps - 60fps /120fps*
XT/HS
; 24fps)
SHUTTER
set shutter angle (5.0°-358.0°; 172,8°;
in High Speed Mode 5.0°-356.0°)*
XT/HS
EI
set exposure index (160ASA - 3200ASA; 800ASA)
WB
set white balance (2000K - 11000K, Auto WB; 5600K;
and CC SHIFT)
