Slide the bridge into position on the rods directly under the lens
support ring on the lens, and fix it in place by tightening the lever on its
side. Align and tighten the center screw in the lens support ring,
adjusting the height of the center screw with the lever on the back of
the lens bridge.
Figure 38: ALEXA with BP-12, 19mm studio rods and lens bridge
