Modem Rear Panel
A
e modem rear panel has the following
connectors and controls:
C
E
B D
WPS button: Begins associating the modem
with a wireless device.
Reset button: Resets the modem as if you
power cycled the unit. Use a pointed non-metallic
object to press this button.
Ethernet (1-4): Connectors for use with a computer
LAN port.
Cable: Connector for the coaxial cable.
Power: Connector for the power cord.
B
A
C
D
E
