Moxi HD DVR FRONT
1 RESET
Resets Moxi.
2 MOXI LED
A glowing white Moxi logo controlled by
settings.
3 NAVIGATION
Left, right, up, down and OK arrows for
direct button input.
4 FRONT USB PORT
USB port.
5 LEDs
If you are recording programs,
corresponding LEDs will appear below
the white Moxi logo.
6 MENU BUTTON
Works identically to the Moxi button
on your remote, taking you to the Moxi
menu.
Moxi HD DVR REAR
7 COMPONENT OUTPUT
Outputs component video.
8 eSATA PORT
To connect an external hard drive.
9 COAXIAL & OPTICAL OUT
Audio out.
10 CABLECARD
Insert your CableCARD from your cable
company.
11 COAXIAL IN
Cable Coax input.
12 COMPOSITE VIDEO
Outputs composite video and base-band
audio.
13 S-VIDEO
Outputs S-video.
14 HDMI
Outputs HDMI audio/video.
15 IR Jack
Used for IR connection
16 USB 2.0
USB connection.
17 ETHERNET
Connect an Ethernet cable to your
broadband internet connection.
18 POWER
Connection for power.
99
