Basic Backup Battery Installation
1 Pull back the battery door latch and remove the battery door. Set the door
aside.
2 Align the guides on the battery with the slots on the Telephony Modem as
shown below, and slide the battery into the bay.
3 Push the battery pack into the bay until it seats into place. Push on the cen-
ter of the battery to avoid inserting the battery at an angle.
Battery Slot
Battery Guide
Touchstone TM602 Telephony Modem User’s Guide
Safety
Getting
Started
Battery
Installation Installation
USB
Drivers
Ethernet
Configuration Usage Troubleshooting Glossary
15
