Installation Guide Touchstone® OG1600 Outdoor Gateway
Release 16 STANDARD 1.0 August 2016 © 2016 ARRIS Enterprises LLC. All Rights Reserved. 5
LED Behavior: Normal Operation
Mode Power LED 2.4G LED 5G LED Online US/DS
AC Power On = Unit is up
and running
Flash = GPS scan
in progress
On = 2.4G Wifi Enabled
Flash = Client activity
Off = 2.4G Wifi Disabled
On = 5G Wifi Enabled
Flash = Client activity
Off = 5G Wifi Disabled
On = Internet
available
On = Connected to
Internet
No AC
Power
Off Off Off Off Off
Firmware
upgrade
Normal
Operation
Normal Operation Normal Operation Normal
Operation
Flash = Firmware
Download in
Progress
LED Behavior: Startup Sequence
Power / GPS Lock US/DS Online
On = OG1600 has power Slow Flash (1 / Second) = Downstream
acquisition in progress
Off
Flash = GPS scan in progress On (Until Upstream Acquisition Starts) Off
On = OG1600 is up and GPS scan
is done
Fast Flash (3 / Second) = Upstream
acquisition in progress
Off
On (Upstream acquisition complete) Slow Flash (during
initialization / IP acquisition)
On (when modem obtain IP address)
