Wiring problems
If the Telephony Modem begins flashing all its lights for more than 10 seconds, this indicates
a problem with the telephone wiring — the red and green wires may be shorted (touching),
or there may be undesired voltage on the lines. If this pattern persists for more than 10
seconds, disconnect the telephone lines from the Telephony Modem, then call a wiring
technician for assistance.
Battery mismatch
If the Telephony Modem alternates flashing the Battery light and all other lights, the
installed battery is incompatible with the Telephony Modem. Remove the battery and install
one of the batteries described in Install and replace the battery (TM804G only) (page 17).
Patterns: normal operation
Table 1: Light patterns during normal operation
Mode Power US/DS Online Link Tel 1/2/3/4 Battery
AC power
good
On
Yellow
1
=
connected to
the Internet
(high speed)
Green
1
=
connected to
the Internet
(ultra-
high speed)
Flash = Not
connected to
the Internet
On = Internet
available
Off = Internet
not available
Yellow
1
= 10/100
BaseT
Ethernet
connected
Green
1
=
1000 BaseT
Ethernet
connected
Off =
computer
not
connected
Flash =
computer
activity
On = on-
hook
Flash =
off-hook
Off =
disabled
On =
battery
good
or low
Off =
battery
missing or
MTA not
registered
Flash =
battery bad
No AC
power /
backup
Flash Off Off Off On = on-
hook
Flash =
off-hook
Off =
battery
power
1
Your service provider may configure the Telephony Modem to always display the DS, US, and Link indicators
in green regardless of the connection speed or swap the meaning (speed indication) of yellow and green)
