Table 19 – Code Modules – Card Download Fields (Page 3)
FIELD DESCRIPTION
MCard Download Channel Download channel configured for the MCard Object
MCard DL PID Download PID detected for the M-Card Object
MCard DL Segment Count
Download segment count, if M-Card object is in the
process of downloading.
MCard DL Status Download status from M-Card:
• 0x00 Idle
• 0x01 WaitDLPID
• 0x02 WaitSeg0
• 0x03 Loading
• 0x04 AuthStor
• 0x05 WaitEnabl
• 0x06 WaitReset
MCard DL Error
• 0x00 None
• 0x01 Segment 0 timeout
• 0x02 Header CRC error
• 0x03 Image CRC error
• 0x04 Image authentication error
• 0x05 Flashing error
• 0x06 Object enable timeout
• 0x07 Done and waiting for reset
• 0x08 Wrong image version
• 0x09 Host busy
• 0x0A Host did not find download PID
MCard Object Name M-Card object name of the object being downloaded.
MCard Object Version M-Card object version of the object being downloaded.
Note: Additional Host Object Table pages will display as the number of software objects increases.
Table 20 – Code Modules – Host Object Table Fields (Page 4)
FIELD DESCRIPTION
Object Name
Name of the software object loaded or downloading onto
the set-top.
Object Version
Version of the software object loaded / downloading onto
the set-top.
