Diagnostics
VMS1100 Hybrid QAM/IP Video Media Server • Installation and Operation Manual
-095-25654 x.1 This document is uncontrolled pending incorporation in an ARRIS CMS
MoCA Power and Attenuation Level
Table 33 – Connected Home – MoCA Power and Attenuation Level Fields
FIELD DESCRIPTION
Attenuation Level Table
Table of the Attenuation and Power associated with
each node in the MoCA network
MoCA transmit attenuation level (dB) for each direct
link between the local device and each MoCA node on
the MoCA network, if available.
The RF transmit power level at the connected MoCA
node expressed in dBm for the link between the
connected node and the STB being polled.
MoCA Rx Power
The RF receive power level at the STB being
polled expressed in dBm for the link between
the connected node and the STB being polled.
