Arrow LW1012FB - Parts Needed for Roof Trim

31
1 Attach the side roof trim pieces to
the lower end of the roof panels on
each side of the building using screws
at each panel overlap.
NOTE
A single screw fastens both trim
pieces at the overlap.
2 Using your thumb and index fin-
ger, overbend the bottom flange of
the side roof trim at the corner inward
enough so the right and left roof trim
caps fit onto right and left corners.
3 Fasten the roof trim caps to the
side trim using a screw.
●●
●●
● 6015 Side Roof Trim (4)
● ●
● ●
● 6014 Side Roof Trim (2)
● Parts Needed For ●
Roof Trim
Step 18
SQ31hw
Tuck Flange
Inward to Fit
Inside of
Roof Trim Cap
STEP
2
Roof Trim Cap
STEP
3
STEP
1
6014
6015
6015
Roof Trim
6014
6015
6015
(4) (8)
