26
(QTY: 17)
(QTY: 80)
Use bolts to attach Wall Panels where Wall Angles overlap.
Place bolt thru center hole where Panels overlap.
Corner Panels lay under Front and Side Panels.
Corner Panel
Attach Wall Panels with screws thru all holes in top and bottom of Panels.
You will need for this page:
Step 8: Continued
Working one side at a time, lift the Panels into
place and secure top and bottom of Panels
with screws. Be sure to overlap ribs as shown
on the previous page.
Place a bolt and nut through the center hole
of the Panel everywhere Panels overlap, as
shown below.
26A
To Next Page
