Insert six (6) bolts into holes.
Six (6) holes align.
10470
10470
(QTY: 16)
Slide parts together until the bottom slots align.
Insert bolts into slots from bottom.
Roof Beam
4
10470
BUILD TWO (2) BEAMS
You will need for this page:
Finished Length
91 7/8” 233,4 cm
Step 3: Roof Beams
Overlap two (2) Roof Beams so that the bottom
slots align as shown. Insert six (6) bolts and
nuts as shown below.
Repeat parts 1 & 2 to build a second Roof
Beam Assembly.
Insert two (2) bolts and nuts into slots on bottom
of the Beam as shown. Check that the fi nished
length of the Assembly is 91 7/8” (233,4 cm).
Set aside for use in Step 12.
6” 15,2 cm
Overlap Length
18A
To Next Page
